Mini Spotlight Recessed Trim Adjustable Φ24-CETTIGA Lighting

C201LED-3W2715

Product Features Size Overview Related Accessories

Mini Spotlight Recessed Trim Adjustable Φ24

Code: C201LED-3W2715

Adjustable light projection design, the finger hole size makes the lighting design more extreme and full of more possibilities.

Applications:Showrooms, Galleries, Restaurants, Museum, Hotels, Bars, Shopping centers and retail stores, etc.

protop_intro_3C-可调.svg

Product overview

MOUNTING	Recessed
SHAPE	Round & Trim
ORIENTATION	Adjustable
ADJUSTABILITY	Tilt 90°, Rotate 350°
IP-RATING	IP20
IK-RATING	IK03
DIMENSION	Ø20x45 mm
CUT-OUT	Ø24 mm
CEILING THICKNESS	5-10 mm
MAIN MATERIAL	Aluminum ADC-12
N.W. / G.W.	0.107kg / 0.157kg
SIZE(CTN)	35.52823.5cm
QTY/CTN	60 pcs/ctn
CONTROL GEAR	Remote
DIMMING	Non-dim
DIMMING OPTION	DALI/1-10V/PHASE/Bluetooth
COLOUR (housing)	Black
COLOUR (reflector)	Black

Optical data

POWER	3W
CCT	2700K
CRI	Ra ≥ 90
BEAM ANGLE	15°
SOURCE FLUX	315 lm
SYSTEM FLUX	79 lm
EFFICACY	23 lm/W
LIGHT SOURCE	LED
LED BRAND	OSRAM
VF	3V
CURRENT	700mA
LED LIFE	50000h@L80
SDCM	SDCM≤5
POWER FACTOR	0.9

Other

MAINS VOLTAGE	220-240V AC
OPTIONAL VOLTAGE	100-240V AC
FREQUENCY	50/60 Hz
TEMP.	-20° C / +40° C
WARRANTY	5 Years
DRIVER OPTION(S)	Tridonic, Meanwell, TCI, LTECH, Euchips, Eaglerise

Downloads Download all

Photometric Files

Ecodesign and Energy Labelling

Replaceable control gear
by a professional
